ARG Baskets
| Model | Pipe Size | A | B | C | D | POLY | #304 SS | Monel |
| ARG-500 | 1/2" | 1.9 | 5.1 | 4.03 | 1.7 | BP-1 | BS-1 | BM-1 |
| ARG-755 | 3/4" | 1.9 | 5.1 | 4.03 | 1.7 | BP-1 | BS-1 | BM-1 |
| ARG-750 | 3/4" | 1.9 | 7.2 | 6.09 | 1.7 | BP-2 | BS-2 | BM-2 |
| ARG-1000 | 1" | 2.6 | 7.3 | 6.09 | 2.4 | BP-3 | BS-3 | BM-3 |
| ARG-1210 | 1-1/4" | 2.6 | 7.5 | 6.09 | 2.4 | BP-4 | BS-4 | BM-4 |
| ARG-1250 | 1-1/4" | 2.6 | 9.4 | 8.00 | 2.4 | BP-5 | BS-5 | BM-5 |
| ARG-1500 | 1-1/2" | 3.1 | 10.1 | 7.80 | 2.9 | BP-6 | BS-6 | BM-6 |
| ARG-2015 | 2" | 3.1 | 10.6 | 7.80 | 2.9 | BP-7 | BS-7 | BM-7 |
| ARG-2000 | 2" | 3.1 | 12.5 | 9.60 | 2.9 | BP-8 | BS-8 | BM-8 |
| ARG-2515 | 2-1/2" | 3.1 | 11.4 | 8.03 | 2.9 | BP-9 | BS-9 | BM-9 |
| ARG-2520 | 2-1/2" | 3.1 | 13.3 | 9.80 | 2.9 | BP-10 | BS-10 | BM-10 |
| ARG-2500 | 2-1/2" | 3.1 | 15.5 | 11.80 | 2.9 | BP-11 | BS-11 | BM-11 |
| ARG-3015 | 3" | 3.1 | 11.9 | 7.80 | 2.9 | BP-12 | BS-12 | BM-12 |
| ARG-3020 | 3" | 3.1 | 13.8 | 9.60 | 2.9 | BP-13 | BS-13 | BM-13 |
| ARG-3025 | 3" | 3.1 | 16.0 | 11.90 | 2.9 | BP-14 | BS-14 | BM-14 |
| ARG-3000 | 3" | 3.1 | 18.3 | 14.20 | 2.9 | BP-15 | BS-15 | BM-15 |
*The above baskets apply to all ARG, AARG & ARGS type strainer models.
